Mark, Lead & Package Inspection

Vision Model
VsMO VsMLO
VsMOP VsMLOP
VsM VsML
VsMP VsMLP

* Top view
* On vision / laser table
* Optional with Orientation checking function

Descriptions
Mark Orientation Mark Lead Orientation
Mark Orientation Package Mark Lead Orientation Package
Mark Mark Lead
Mark Package Mark Lead Package

Illustration

Lead Inspection

Lead (width, pitch, length, length variance, span, offset skew) results by vision mark lead package inspection

Package Inspection

Package (scratches, contamination, chipped off, incomplete mold, void, flashes, crack) results by vision mark lead package inspection

Mark Inspection

Mark (wrong, shifted, missing, scratches, tilted, misaligned, excess, contrast, extra, broken, double, no mark, illegible) vision mark lead package inspection Mark (wrong, shifted, missing, scratches, tilted, misaligned, excess, contrast, extra, broken, double, no mark, illegible) results by vision mark lead package inspection Mark results by vision mark lead package inspection

*Available when the feature is turned on.
**Available when the features is turned on and there is package inspection.
